1.20 - 14.20mm Dinding Tabung Stainless Steel 5 Inch, Tahan Lama 321 Pipa Stainless

  • 1.20 - 14.20mm Wall 5 Inch Stainless Steel Tubing , Durable 321 Stainless Pipe
  • 1.20 - 14.20mm Wall 5 Inch Stainless Steel Tubing , Durable 321 Stainless Pipe
  • 1.20 - 14.20mm Wall 5 Inch Stainless Steel Tubing , Durable 321 Stainless Pipe
  • 1.20 - 14.20mm Wall 5 Inch Stainless Steel Tubing , Durable 321 Stainless Pipe
Tempat asal BUATAN CHINA
Nama merek JUYE
Sertifikasi ISO
Nomor model 321
Kuantitas min Order Negosiasi
Harga negotiation
Kemasan rincian ekspor paket
Waktu pengiriman Dalam waktu 4 minggu
Syarat-syarat pembayaran 20% T / T pada PO, 80% sebelum pengiriman atau L / C yang tidak dapat dibatalkan pada saat penglihat
Menyediakan kemampuan 800T
Detail produk
Deskripsi pipa baja dilas Kelas 321
GAUGE 13.50-410mm Ketebalan dinding 1.20-14.20mm
Standar EN10217-7: 2005 Panjang sesuai permintaan
Aplikasi Pipa Cair Industri
Cahaya Tinggi

tabung dilas stainless steel

,

stok tabung stainless steel
Tinggalkan pesan
Deskripsi Produk
Detail Cepat:

Keterangan: Pipa las baja tahan karat

Grade: 321

Standar: EN10217-7: 2005

Gauge: 13.50-410mm

Tembok ketebalan: 1.20-14.20mm

Ukuran: lihat di sini di bawah tabel terlampir "kisaran ukuran"

Ukuran Rentang

Gauge (mm) Ketebalan Dinding Nominal (mm)
1,20 1,60 2.00 2,30 2.60 2,90 3.20 3.60 4.00 4.50 5.00 5.60 6.30 7.10 8.00 8.80 10.00
13.5 ● ● ● ●
17.2 ● ● ● ●
21.3 ● ● ● ● ●
26.9 ● ● ● ● ● ●
33.7 ● ● ● ● ● ● ●
42.4 ● ● ● ● ● ● ● ●
48.3 ● ● ● ● ● ● ● ● ●
60.3 ● ● ● ● ● ● ● ●
76.1 ● ● ● ● ● ● ● ● ●
88.9 ● ● ● ● ● ● ● ● ● ●
101.6 ● ● ● ● ● ● ● ● ● ●
114.3 ● ● ● ● ● ● ● ● ● ● ●
139.7 ● ● ● ● ● ● ● ● ● ● ●
168.3 ● ● ● ● ● ● ● ● ● ● ● ●
219.1 ● ● ● ● ● ● ● ● ● ● ● ● ●
273 ● ● ● ● ● ● ● ● ● ● ●
323 ● ● ● ● ● ● ● ●
355.6 ● ● ● ● ● ● ● ● ●
406.4 ● ● ● ● ● ● ● ● ●

Komposisi kimia

Standar: EN10217-7

Grade: 1.4541

C: 0,08%

Si: 1,00%

Mn: 2,00%

P: 0,045%

S: 0,03%

Ni: 9% ~ 13%

Cr: 17% ~ 19%

Ti: 5 * C%

Karakteristik Mekanik

EN10217-7 Kelas Kekuatan Hasil Daya tarik Pemanjangan Kekerasan
N / mm2 N / mm2 % HRB
1,4541 ≥205 ≥520 ≥40 ≤90

Keuntungan dari Pipa Cair Stainless Steel

Pipa cairan stainless steel aman, andal, sanitasi, ramah lingkungan, ekonomis dan berlaku. Dinding pipa tipis, dan metode koneksinya sederhana dan nyaman

Aplikasi Utama:

  • Petrokimia
  • Pembuatan kertas
  • Energi
  • Uap
  • Rekayasa Limbah
